Model Name/Number	CH-430 x 1100
Swing Over Bed	432 mm
Layout	Horizontal
Warranty	1 Year
Brand	Kinwa
Material	Mild Steel
Swing Over Carriage	268 mm
Swing Over Gap	610 mm
Width of Bed	300 mm
Stroke of Tool Post	145 mm
Stroke of Cross Slide	265 mm
Quill Stroke	170 mm
Quill Diameter	60 mm
Quill Taper	MT 4
Lead Screw Diameter	35 mm
Number of Feeds	36

Known as a renowned organization, we are involved in offering a wide range of Horizontal Lathe Machine to fulfill the needs of our customers. Horizontal Lathe Machine light in weight and are easy to operate. These products are precision engineered and ensure longer functional life. A team of skilled professionals and efficient workers of the industry construct these products with set industrial norms.

Features:

• High performance
• Ruggedness
• Durability
• Bed is made of meehanite and is hardened and precisely ground, Hardness is HS 70 degree.
• Automatic and manual forced Lubrication pump supplies oil to cross slide and bedways.
• Oil distributor may be adjusted to lubricate bedway, cross slide, or both.
• Starting lever with safety device.
• Emergency foot-operated braking system.
• Headstock-Gear in the headsotck are treated by cementation and precisely ground. Forced lubrication system is employed. HP Model with P5 grade spindle bearing is optional.
• Gear Box-It offers a comprehensive range of inch and metric threads without the use of change gears. All gears in the gear box are hardened.
• Apron-Apron is equipped with a manual and automatic lubrication system. It will keep cross slide ways and bedways clean and lubricated. The apron is equipped with an overload protection device to avoid machine damage.

Standard Equipment & Accessories

• Leveling screws
• Service kits & Tool box
• 9" backplate
• Main motor 5HP / 4P
• Coolant system
• Multi - position length stop

Optional Equipment & Accessories

• Center sleeve MT6 x MT4
• Dead center ( MT4 ) 2 PC
• 7" backplate
• Steady rest
• Follow rest
• Face plate ( 350 mm )
• Turret micro carriage stop
• Taper turning attachment
• 3 - jaw chuck
• 4 - jaw chuck
• Work light
• Rear toolpost
• Main motor 7.5HP / 4P
• Full length splash guard
• Drill attachment
• Spindle bore 78mm ( for CH430 / 530 )
